DLT-1
ECH
Electronic Flush Sliding Door System with Two-way Damper for Doors Up To 80kg
Specification
Product Features
①Maintain the same level as the wall surface
②Beautiful and invisible door
③Perfect functions,safe and practical
Technical Parameterfully open
Material:Aluminum alloy,cast steel
Maximum load:80 KG
Door width:≥600mm
Door thickness:≤55mm
Main use:wooden doors
Product NO: DLT-1
Product Description:Ghost door sliding system for wooden doors
Product Specification:
1. Main Material: Aluminum alloy,cast steel
2. Finish: Silver Anodization
3. Rail Length: Customized (normally 1000mm)
4. Max Loading: 80kg with soft closer
5. Durability: 100000 workcycles
6. Suitable for residential use.
7. Soft closing included
Packing Method
Each set into a Carton as a sales unit(1 set/ctn), then proper quantity a wooden pallet.
EXW, MOQ 112 sets Due to frequent fluctuations in raw materials and exchange rates, the price is subject to final confirmation before ordering
| Type | Flush Sliding Door System |
| Brand name | ECH |
| Model NO. | DLT-1 |
| Material | Aluminum alloy,cast steel |
| Finish | satin zinc or to order |
| Max door weight | 80KG |
| Door thickness | 55mm |
| Door width | ≥600mm |
| Inner packing | soft foam pastic bag,color box and blister packing |
| Standard export packing | one piece in one plastic bag,one pair in one white box ,20 pairs in one carton |
| Delivery day | 30 working days |
— Limited number of parts for easy installation.
— The two-way damper allows doors to be both opened and closed softly.
— No bottom rail or floor groove is necessary.
— Improved adjustments for a perfect result.
— Doors will be flush with walls when closed.
— Door can be pushed open and no handle is necessary on the door front.
Product picture
