Black Coated Roller Hardware Barn Door Floor Guide Adjustable with Accessories
Black Powder coated
Ajustable Wall Mount Guide with 8 different setups
Perfect fit for All barn doors Bottom.
Model number: FG10A-BLK
Material: Stainless Steel/Steel
Surface finish:black/dark coffee powder coating or other color as required
Load bearing: 175kgs
Application: interior/exterior wooden doors for living room/store room/veranda/laundry.etc
Single/double open wooden door
Rail/track length: 2m/79" standard or as customized
Door thickness : 1 3/8" --1 5/8" (35-45MM)
Door width:31 1/2" --39 3/8"
Packing:2055*115*80/set
Warranty: 3--5years
Track length&door width Match: 1500mm track--under 750mm door
1800mm track--under 900mm door
2000mm track--800-1000mm door
3000mm track(1500+1500)--1500mm door
1 set include:
Door stopx2,sliding trackx1, wall mountx5,sliding rollerx2,bottom guidex1,door handle(selective)x1, anti-jump diskx1
| | | |
Sliding Track(Length can be customized.) | | Carbon Steel +black powder coating / painting |
| | | Carbon Steel +black powder coating / painting |
| | | Carbon Steel +black powder coating / painting |
| | | Carbon Steel +black powder coating / painting |
| | | |
| | | |
Door Handle(not included in the kit) | | Carbon Steel +black powder coating / painting |
Detailed Photos
