Movable ALuminum office partition sliding folding type aluminum partition

Movable ALuminum office partition sliding folding type aluminum partition
Availability:
Quantity:
Inquire Add to Basket

  • TYPE65

  • ECH

Movable ALuminum office partition sliding folding type aluminum partition

Welcome a trial order!

Contact us at any time!

lever set

  • General Use:Commercial Furniture, Commercial Furniture

  • Type:Office Furniture, Office Furniture

  • Mail packing:N

  • Application:Hotel, Office Building, School, Mall, OTHER, Hall, Office, commercial building, home ect.

  • Design Style:Modern

  • Place of Origin:Guangdong, China

  • Brand Name:ECH

  • Model Number:type65 ,80 100

  • Frame Color:aluminium anodized color or customized color

  • panel thickness:65mm,80mm,125mm,

  • Surface material:mdf,plwyood, Magnesium board

  • Certificate:CE, ISO9001, SGS

  • Name:ECH

  • Size:Custom Sizes

  • Technical data of Type 65 movable partition :





    Model
    Weight (kg/m)
    Fire Rating (min)
    STC Performance
    Specification
    Thickness (mm)
    Width (mm)
    Heigth (mm)
    Top Seal (mm)/Pressure (kg)
    Bottom (mm)/Pressure(kg)
    LCP stretch (mm)
    EG65-22
    22
    60
    32db
    65
    680-1212
    2000-4500
    22.5/35
    22.5/35
    140
    EG65-38
    27
    60
    38db
    65
    680-1212
    2000-4500
    22.5/35
    22.5/35
    140
    EG65-45
    25
    60
    45db
    65
    680-1212
    2000-4500
    22.5/35
    22.5/35
    140

    Technical data of Type 80 movable partition :
    Model
    Weight (kg/m)
    Fire Rating (min)
    STC Performance

    Thickness (mm)
    Width (mm)
    Height (mm)
    Top Seal (mm)/Pressure (kg)
    Bottom Seal(mm)/Pressure (kg)
    LCP stretch (mm)
    EG80-40
    30
    60
    40db
    80
    680-1212
    2000-5500
    22.5/35
    22.5/35
    140
    EG80-45
    38
    60
    45db
    80
    680-1212
    2000-5500
    22.5/35
    22.5/35
    140
    EG80-48
    47
    60
    48db
    80
    680-1212
    2000-5500
    22.5/35
    22.5/35
    140

    Technical data of Type 100 movable partition :
    Model
    Weight (kg/m)
    Fire
    Rating
    (min)
    STC
    Performance
    Specification
    Thickness (mm)
    Width (mm)
    Height
    (mm)
    Top Seal (mm)/Pressure (kg)
    Bottom Seal(mm)/Pressure(kg)
    LCP
    Stretch
    (mm)
    EG100-43
    38
    60
    43db
    100
    680-1219
    2000-7500
    30/40
    30/40
    140
    EG100-48
    46
    60
    48db
    100
    680-1219
    2000-7500
    30/40
    30/40
    140
    EG100-53
    55
    60
    53db
    100
    680-1219
    2000-7500
    30/40
    30/40
    140


    brushed nickel door levers
